Single Door Magnetic Lock(EL-750)
which can withstand 1500Lbs holding force.Suitable for glass door, heavy door,wooden door, fireproof door, sliding door and metal door and so on.The Special design to prevent the residual magnetism makes the access control automation safer and electric lock more durable.
Collinear Load Test 750kg,1500pounds.
Dual Voltage 12 or 24 VDC(optional).
The Standard Voltage is 12VDC when Finished.
MOV Provides Reverse Current Protection.
Anti-Residual Magnetism Designed.
High Strength Material,Anodized Aluminum Housing.
Design without Mechanical Failure.
Increase the holding Force,Dual Insulative Housing.
CE Certificate by European Union,MA Certificate by China Public Security Office.
N/A
|
Product Parameter
|
Parameter Description
|
|
Size
|
280Lx81.6Wx46H(mm)
|
|
Armature plate
|
190Lx70Wx13H(mm)
|
|
Holding Force
|
750kg(1500Lbs)
|
|
Voltage
|
12 or 24VDC
|
|
Current Draw
|
12V/420mA 24V/210mA
|
|
Suitable for
|
Wooden door , Glass door ,Metal door , Fireproof door
|
|
Surface Temp
|
≤+20℃
|
|
Operating Temp
|
-10～+55℃(14-131F)
|
|
Suitable Humidity
|
0~95%(non-condensing)
|
|
Finishes for Shell
|
Anodized aluminum
|
|
Finishes for Magnetic
|
Zinc
|
|
Finishes for Armature
|
Zinc
|
|
Weight
|
5.9kg
|
