Double Door Magnetic Lock(EL-350D)

Double door electric lock mainly for wooden door, fireproof door, sliding door and metal door. Holding is 800lbd on each side . LED indicator fixed to indicate the lock status. Inbuilt dry contacts lock status signal output ( NO,NC,COM).

  • Overview

  • Feature

  • Specification

  • Configuration

  • Download

Collinear Load Test 350x2kg,800x2pounds.

Dual Voltage 12 or 24 VDC(optional).

The Standard Voltage is 12VDC when Finished.

MOV Provides Reverse Current Protection.

Suitable For Wooden Door,Glass Door,Metal Door,Fireproof Door.

LED Indicates the Door Status.

Lock Status sensor(NO/NC/COM).

Anti-Residual Magnetism Designed.

High Strength Material,Anodized Aluminum Housing.

Design without Mechanical Failure.

Increase the holding Force,Dual Insulative Hosuing.

CE Certificate by European Union,MA Certificate by China Public Security Office.
N/A
Product Parameter Parameter Description
Lock Size 570Lx55Wx27.5H(mm)
Armature plate 190Lx45Wx11H(mm)
Holding Force 350kgx2(800Lbsx2)
Voltage 12 or 24VDC
Current Draw 12V/480mA*2 or 24V/240mA*2
Signal Output Dry Contact,Max Rating of Contact Current 3A
LED Red indicates the door is unlock,Green indicates the door is lock
Suitable for Wooden door , Glass door ,Metal door , Fireproof door
Surface Temp ≤+20℃
Operating Temp -10~+55℃(14-131F)
Suitable Humidity 0~95%(non-condensing)
Finishes for Shell Anodized aluminum
Finishes for Magnetic Zinc
Finishes for Armature Zinc
Weight 5.4kg
