Fail safe electric bolt W/signal, time, open wire(12-24V) EL-300

EL-300 is a Multi-functional fail safe electric bolt .with Double protection for loading current.suitable for glass door, wooden door, metal door . We supply integrated equipment to collocate with fully frame-less glass door, swing-in door and so on. Build-in Photo electricity control and low temperature design.

  • Overview

  • Feature

  • Specification

  • Configuration

  • Download

Low Temperature, safe & Durable.

Low Power, Environmental Protection.

Special photoelectricity control,three steps current application.

Long Life  with 500000 cycles.

MOV Provides Reverse Current Protection.

Superior Strength Aluminium Alloy,Solid Stainless Steel Bolt.

Autolock Time Delay: 0,3,6,9sec.

Door statue signal output contact(NC.COM).

Double protection for loading current.

Auto-relock if no Action within 5 secs.

Certificate:CE&MA.

Photoelectricity Control,Low Temperature，

  A:The  Low Current is Changed immediately;

  B:When door frame doesn`t coincide with door leaf ,door leaf against the bolt,then the electric bolt will start the low-power function to bring low temperature.

  C:The Photoelectricity Control Technology,prevent the machanical defect.

N/A

    New product
