Single Door Magnetic Lock With Mortise Mount(EL-180M)

Single door electric lock with mortise mount is for glass door, wooden door, small size door with a holding force of 350lbs. The material is aluminum. Anti-residual magnetism is its selling point and makes electric lock more durable.

  • Overview

  • Feature

  • Specification

  • Configuration

  • Download

Collinear Load Test 180kg,350pounds.

Dual Voltage 12 or 24 VDC(optional).

The Standard Voltage is 12VDC when Finished.

MOV Provides Reverse Current Protection.

Anti-Residual Magnetism Designed.

High Strength Material,Anodized Aluminum Housing.

Design without Mechanical Failure.

Increase the holding Force,Dual Insulative Housing.

CE Certificate by European Union,MA Certificate by China Public Security Office.

N/A
Product Parameter Parameter Description
Size 190Lx31.5Wx22.5H(mm)
Armature Plate Dimension 130Lx33x9.3H(mm)
Holding Force 180kg(350Lbs)
Input Voltage 12 or 24VDC
Current 12V/300mA   or   24V/150mA
Suitable Wooden door , Glass door ,Metal door , Fireproof door
Surface Temp ≤+20℃
Operating Temp  -10~+55℃(14-131F)
Humidity  0~90%(non-condensing)
Cover Finish Anodized aluminum
Lock Finish Zinc
Armature Plate Finish Zinc
Weight 1.2kg
