YM-280IS(LED) is a new type of single door Electromagnetic Lock with the infrared induction automatic unlock function, Due to it can improve the efficiency of Access control automation effectively, It’s widely used in Emergency Exit of intelligent building, residential community, shopping center, airport, HSR station, subway station, the grand theatre and so on.
Infrared sensors device, 3 meters detection distance.
130 degrees of infrared human induction angles.
High brightness LED displays the status of an electric lock.
Dual voltage 12 or 24 VDC(optional).
Signal output of lock, NO/NC/COM.
High strength magnetic lock cylinder designed; Strong electromagnetism force.
The latest industrial design, safety and steady .
|
Product Parameter
|
Parameter Description
|
|
Size
|
283Lx48.8Wx39.9H(mm)
|
|
Input Voltage
|
DC12V or DC24V
|
|
Current
|
12V/ 520mA; 24V/ 260mA
|
|
Holding Force
|
280kg(600Lbs)
|
|
Signal Output
|
Lock signal(NO/NC/COM)
|
|
LED
|
Red shows locked; Green shows unlocked
|
|
Time Delay
|
3/6/9/12sec adjustable
|
|
Suitable for
|
Wooden door, Glass door, Metal door, Fireproof door
|
|
Detection range
|
3m
|
|
Weight
|
2.6KG
|
